| 主要技術(shù)參數(shù) | |
| 型 號Model | GPSTS005 |
| GPS頻 率Frequency range | 1575.42MHz±3 MHz |
| GSM頻 率Frequency range | 824MHz-894MHz，880MHz-960MHz，1710MHz-1990MHz |
| 駐 波VSWR | ≤1.5 |
| 增 益Gain | 3DBi |
| GPS放大增益Amplification Gain | 30DBi |
| 極化型式Polarization | Vertical or Horizontal |
| 最大功率Maximum input power | 50W |
| 輸入阻抗Impedance | 50Ω |
| 線型Cable type | RG174 |
| 線長Length | 3M or 5M |
| 接口型式Input Connector | SMA/SMB/SMC/BNC/FME/TNC/MCX /MMCX |
| 天線尺寸Dimensions of Antenna | ?96×126mm |
| 工作溫度Working Temp | -40℃~+85℃ |
| 重 量Weight | ＜100(克)gram |
