| 電氣參數(shù) Electric Spec | |
| 型號Model | BZ2400TS002 |
| 頻率Frequency rang | 2400～2483MHz |
| 駐波VSWR | ≤1.5 |
| 增益Gain | 8dBi |
| 極化型式Polarization | 水平或垂直Horizontal or Vertical |
| 水平波瓣寬度Horizontal beam width | 60° |
| 垂直波瓣寬度Vertical beam width | 40° |
| 最大功率Max power | 50W |
| 輸入阻抗Input Impedance | 50? |
| 接口型式Connector model | N Female |
| 機械參數(shù) Mechanical Specification | |
| 天線尺寸Size | 115*115*27mm |
| 重 量Antenna weight | 0.08kg |
| 安裝方式 | 底盤固定 |
| 抗風(fēng)強度Rated Wind Velocity | 60-m/s |
