| 電氣性能ELECTRICAL | |
| 型號(hào) Model | CZ4GTS004 |
| 頻率范圍 Frequency Range | 700-2700MHz |
| 帶寬 Bandwidth | 2000 -MHz |
| 增益 Gain | 7dBi |
| 電壓駐波比 VSWR | ≤1.5 |
| 極化方式 Polarization | 垂直 Vertical |
| 最大功主率 Max power | 50 -W |
| 輸入阻抗 Nominal Impedance | 50 -Ω |
| 機(jī)械參數(shù)MECHANICAL | |
| 接頭型號(hào) Connector | SMA座或客戶指定 SMA female or customized |
| 天線尺寸 Antenna Dimension | 30×320-mm |
| 線型 Wire | RG174 female or customized |
| 固定方式 Fixed form | 磁性 Magnetism |
