| 電氣性能ELECTRICAL | |
| 型 號(hào)Model | ZD315433TS001 |
| 頻 率Frequency range | 315MHz/433MHz |
| 駐 波VSWR | ≤2.0 |
| 增 益Gain | 2.5DBi |
| 極化型式Polarization | 垂直Vertical |
| 最大功率Maximum input power | 50W |
| 輸入阻抗Impedance | 50Ω |
| 接口型式Input Connector | SMA Male |
| 天線尺寸Dimensions of Antenna | Φ8×47mm |
| 重 量Weight | 16g |
